POWER4
Class D Active Module 4 Ohm for Subwoofer Enclosures
Efficient Class D Mono Amplifier
1 x 460 Watts RMS @ 4 Ω
Efficiency up to 84%
Lowpass 40-120 Hz @ 12 dB
Phase Switch 0°/180°
Bass Boost 0-6dB @ 45Hz
RCA Low Level Input
High Level Input
Auto Turn-On Function (DC or signal)
Start-stop capable, 5 sec./ up to 7 Volts
EPS PRO with 10R / 150R / 600R (switchable)
Input Sensitivity 15 or 40 Volts (switchable)
Triple Limiter Function, Clipping LED
Bass Level Remote Controller
Suitable for housings with Quick Connect terminals
Dimensions: 113 x 130 x 125mm
Mounting hole: 85 x 109 mm
Downloads:
Owner's Manual
Test Review
* Manufacturer's suggested retail price, changes and mistakes reserved
