CONCHORD CW 12 D2
CW 12 D2
SUBWOOFER CONCHORD 12"
POWER HANDLING
600W RMS 1%THD/1200W MUSIC/1800W PEAK
TECHNICAL SPECIFICATIONS
IMPEDANCE:Zn 2+2 OHM
VOICE COIL DIAMETER:@ 3 INCH
VOICE COIL WINDING HEGTH:42mm
MAX LINEAR EXCURSION:Xmax +/-21 mm
MAX MECHANICAL EXCURSION:X mech +/-30 mm
CONE AREA: Sd 490,9 mm2
MOVING MASS:Mms 196,5g
DC RESISTANCE: Re (series) 4,6 Ohm (3,6)*
RESONANCE FREQUENCY: Fs 41 Hz (34)*
MECHANICAL Q FACTOR: Qms 10,5 (8,4)*
ELECTRICAL Q FACTOR:Qes 1,52 (1,2)*
TOTAL Q FACTOR:Qts 1,33 (1,1)*
EQUIVALENT AIR VOLUME: VAS 25,7L (25)*
FLUX DENSITY:B/L 12,38 N/A
EFFICIENCY 2,83v/1m: SPL 89,3 dB
* AFTER BURN-IN PERIOD
MECHANICAL SPECIFICATIONS by Kod.
-STEEL BASKET
-NON PRESSED PAPER CONE
-FOAM SURROUND
-PP DUSTCAP
-DUAL SPIDER
-MAGNET 157X85X40
-HIGH POWER BASV VC
DIMENSIONS AND WEIGHT
-EXTERNAL DIAMETER 315 mm
-MOUNTING DIAMETER 270 mm
-MOUNTING DEPTH 160 mm
