Highlights
Extremely powerful 120 mm single magnet
High-strength fiberglass/foam/paper cone
38 mm dual voice coil with copper wire
Temperature-resistant polyimide voice coil former
Ventilated steel basket
Durable ConnexTM center spider and rubber surround
Corrosion-resistant, gold-plated contact terminal
Magnetic protection with AXTON logo
Low mounting depth 80 mm
Specifications
Frequency response 55 - 300 Hz
Nominal impedance 2 x 2 Ohm
Sensitivity (1 W/1 m) 86.7 dB
Nominal power handling 75 W RMS
Maximum power handling 150 W max
Mounting diameter 184 mm
Installation depth 80 mm
