AMPIRE Mono Digital Class D Amplifier, 1x 500 Watt, 24 volts
Mono Digital AmplifierUltra-Compact DesignCinch & Speaker Inputs500 Watt RMS/1000 Watt max.Illuminated AMPIRE Logo
Χαρακτηριστικά:Power SupplyPower supply voltage: 20 - 32 VDCRemote voltage: 8 - 28 VDCIdling current: 0,86AIdling current when off: <0,4mAAmplifier StageOutput power (RMS) @ 28,8V / 4 Ohm: 300 Watt x 1Output power (RMS) @ 28,8V / 2 Ohm: 500 Watt x 1Output power (max.) @ 28,8V / 4 Ohm: 600 Watt x 1Output power (max.) @ 28,8V / 2 Ohm: 1000 Watt x 1Distortion (THD): <0,5%S/N Ratio: >85dBInput sensitivity: 200mV - 6,0VFiltersLow pass filter/slope: 30Hz - 250Hz / 12dBBass Boost/Frequency: 0 - 12dB / 40 - 100Hz variableOther FunctionsFuse: 25A x 2Max size: (LxWxH) 251 x 141 x 50mmWeight: 1,90KgInputs: RCA x2, High Level x2 (High Level Auto Turn On)Type approval:- E8 10R-04 1282
