1000 Watts SPL
8″ high quality SPL subwoofer with reinforced paper cone
8″ high quality SPL subwoofer
Klippel® optimized
Reinforced paper cone
Long stroke compound surround
Resonance free steel basket
50 mm / 2″ copper voice coil
Polycot spider
IMPP dust cap with 3D structure logo
Model
High-Quality SPL subwoofer
Diameter
20 cm / 8"
Power Handling (RMS/SPL.)
500 / 1000 Watts
Impedance
2x 2 Ohms
Efficiency
84.6 dB
Power Recommendation
400 – 1000 Watts
Voice Coil
50 mm / 2" copper
Membran Layout
Reinforced paper
Max. Excursion (Xmax)
22 mm / 0.866"
Mounting Ø
182 mm / 7.17"
Mounting Depth
133 mm / 5.24"
Resonance Frequency (Fs)
45.8 Hz
Overall Qaulity (Qts)
0.36
Equiv. Air Volume (Vas)
7.4 L / 0.26 cu.ft.
