600.4 EVO 5 – 4 OHMS
Power @ 2Ω: 4 x 150W
Power @ 4Ω: 4 x 100W
Bridge Power @ 4Ω: 2 x 300W
Bridge Power @ 8Ω: 2 X 198W
Frequency Response (-3dB):
10Hz ~ 20kHz
Low Pass Filter:
80Hz
High Pass Filter:
80Hz
Operating Voltage:
8V ~ 16V
SNR:
88dB
Input Sensitivity:
0.2V ~ 2V
Current Draw (Music):
27A
Current Draw With Resistive Load:
54A
Total Efficiency:
88%
Damping Factor:
200
Power Cable:
10mm² (7AWG)
Audio Output Cable:
2 x 1.5 mm² (15 AWG)
Recommended Fuse (Music):
40A
Recommended Battery:
40Ah
Width:
4.45 in / 11.3 cm
Length:
5.33 in / 13.5 cm
Height:
2 in / 5.09 cm
Weight:
0.66 Kg
