400.2 EVO 5 – 4 OHMS
Power @ 1Ω: N/A
Power @ 2Ω: 2 x 200W
Power @ 4Ω: 2 x 132W
Bridge Power @ 4Ω: 1 x 400W
Bridge Power @ 8Ω: 1 X 264W
Frequency Response (-3dB):
10Hz ~ 20kHz
Low Pass Filter:
80Hz
High Pass Filter:
80Hz
Operating Voltage:
8V ~ 16V
SNR:
90dB
Input Sensitivity:
0.2V ~4V
Current Draw (Music):
18A
Current Draw With Resistive Load:
36A
Total Efficiency:
88%
Damping Factor:
200
Stereo Channel Minimum Impedance:
2Ω
Bridge Minimum Impedance:
4Ω
Recommended Fuse (Music):
20A
Recommended Battery (Minimum):
35Ah
Width:
4.4 in / 11.3 cm
Length:
4.7 in / 12.1 cm
Height:
2 in / 5.1 cm
Weight:
0.48kg
