3000.1 EVO 5 – 1 OHM
Power @ 1Ω: 1 X 3000W RMS
Power @ 2Ω: 1 X 1980W RMS
Power @ 4Ω: 1 X 1307W RMS
Frequency Response (-3dB):
5Hz ~ 25kHz
Subsonic Filter:
5Hz ~ 80Hz
Low Pass Filter:
50Hz ~ 1kHz
Bass Boost:
0dB ~ 12dB @ 50Hz
Operating Voltage:
9V – 16V
SNR:
92dB
Input Sensitivity:
0.2V ~ 2V
Current Draw (Music):
1Ω: 149A
2Ω: 139A
4Ω: 140A
Current Draw With Resistive Load:
1Ω: 298A
2Ω: 277A
4Ω: 280A
Total Efficiency:
1Ω: 80%
2Ω: 86%
4Ω: 85%
Damping Factor:
>2000
Power Cable:
35mm² (2AWG)
Audio Output Cable:
1Ω: 2 x 4.0 mm² (11 AWG)
2Ω: 2 x 2.5 mm² (13 AWG)
4Ω: 2 x 1.5 mm² (15 AWG)
Recommended Fuse (Music):
150A
Recommended Battery:
150Ah
Width:
5.3 in / 13,6 cm
Length:
8.9 in / 22,9 cm
Height:
2.1 in / 5,48 cm
Weight:
1,65 Kg
