8-channel DSP
4-channel amplifier with integrated 8-channel DSP, 6-channel high-level/5-channel RCA input, USB connection, digital and AUX input as well as auto-on function
8-channel digital signal processor
High-level and line input
Realtime setting
32 bit Cirrus Logic Prozessor
Windows GUI software
Separate 31 band equalizer for each channel
Time delay
Variable crossover
Phase correction
Automatic turn-on function for the high level input
Adapter for wireless music streaming available separately (GZDSP BTB-APP)
Wired remote control available separately (GZDSP REMOTE PRO-X)
Model
4-channel amplifier with digital signal processor
High Resolution Compatibel
yes
TOSLINK & Coaxial Input
24-bit / 12 -192 kHz
AUX Connector
3.5 mm socket
High-Level Audio Mix
up to 6 channels
Frequency Response
20 Hz – 20 kHz (-3 dB)
Signal-to-Noise
> 100 dB
Input Sensitivity
0.6 – 5 V (AUX) / 2 – 15 V (high-level)
max. Ausgangsleistung (CEA-2006A / 10%THD+N)
4x 130 Watts max @ 2 Ohms
Output Power
4x 80 Watts RMS @ 4 ohm
Remote
optional
Preset Memory
10
Dimensions (W x L x H)
185 x 237 x 42 mm / 7.28" x 9.33" x 1.65"
